SWK Termo Top

SWK Termo Top

The SWK DHW cylinders is an energy-saving device of unrivaled quality. The connectors facing up enable mounting the DHW cylinders directly under the boiler and thus save a lot of space.

In a nutshell:

  • standing heat cylinder with coil
  • capacity: 100L - 140L
  • connectors facing up
  • energy class A
Kospel
Description

The highest energy efficiency of the heat cylinder

Thanks to the very good insulation of 65mm PUR foam, the SWK DHW cylinder has energy class A. You reduce heat loss by up to 50% and gain up to 320kWh of energy saving per year compared to class C heat cylinders.

Get unrivaled quality

Our products are made of selected steel grades supplied by reliable suppliers. For your confidence and safety, all of our DHW cylinders pass tightness tests and enamel layer quality inspections.

Advanced production technology

The automated production of our heat cylinders guarantees repeatability and precision of workmanship. A homogeneous layer of enamel coating of an appropriate thickness forms the top-quality corrosion protection.

Technical data
Product code Storage capacity (l) Surface area of coil (m2) Rated pressure (storage / coil) (MPa) Power of coil (kW) Thickness / material / type of insulation (mm) Stand-by-losses (W) Anode type
SWK-100.A 97 0,82 0,6 / 1,0 MPa 25 65/PUR/NR 33 AMW.M8.450
SWK-120.A 111 1,0 0,6 / 1,0 MPa 30 65/PUR/NR 36 AMW.M8.450
SWK-140.A 134 1,1 0,6 / 1,0 MPa 32 65/PUR/NR 38 AMW.M8.450
SWK-150.A 150 1,14 0,6 / 1,0 MPa 33 70/PUR/NR 39 AMW.M8.450

* Detailed warranty conditions are described in the warranty card

** Following parameters 80/10/45 C – (heating water temp./ feed water temp./domestic water temp.), flow rate of heating water through the coil 2,5 m3 /h.

*** Insulation: R- removable, NR- not removable

**** In line with EU Commission resolution no. 812/2013, 814/2013.

Dimensions
Product code Diameter (mm) A (mm) B (mm)
SWK-100.A 595 906 127
SWK-120.A 595 1018 127
SWK-140.A 595 1140 127
SWK-150.A 690 940 130
